Copra Oil Press Machine
Copra screw oil press is an essential part in the coconut oil extraction plant. If you are thinking to start a coconut oil business and want to purchase high quality coconut oil extraction machine for small to large scale coconut oil production plant, you are in the right place! Buy copra oil press machine directly from the manufacturer.
For manufacturing coconut oil, we provide you various different capacities of copra oil press machines. We have the small scale oil press to large scale oil press machines.
Small Scale Copra Oil Press Machine
It is widely used in small sized coconut oil factories, due to its features of small in size and efficient production.
- Production Output : 2 – 3 ton per day
- Single Reduction Gear Box with Spur Gears.
- Fabricated chamber size : 24″ long x 4″ Diameter.
- Case hardened worm assembly.
- Chamber size 4″ x 24″ Long
Medium Scale Coconut Oil Press Machine
This screw press is featured of high oil yield and ideal for medium scale oil mill plant and new entrepreneur.
- Production Output: 12- 15 tonnes per 24 Hours
- Chamber Size 44″ X Ø7″ Long.
- Double Reduction Gear Box of Cast Iron Body and Mild Steel Fabricated Gears.
- Case Hardened Worm Assembly and Cone Point.
- Steel Fabricated Base.
Large Scale Copra Oil Press Machine
This machine is the best choice for large scale copra oil mill plant
- Production Output: 45 – 125 ton per day
- This model has been designed in a simple and symmetrical shape.
- Triple Reduction Gear Box with helical gears of cast steel and pinion shafts of special steel.
- Worm Assembly, discharge ring, Sliding ring are all hard faced.
Technical Details about some of our Screw Oil Press:
| Model | Capacity | Power (HP) | Length | Breadth | Height | |
|---|---|---|---|---|---|---|
| Expeller Motor | Kettle Motor | |||||
| GOYUM 60 | 5 – 6 Ton per 24 Hours | 3 Phase, 20 HP, 960 RPM | – | 8’12” | 2’11” | 6’12” |
| GOYUM MK-III | 8 – 10 Ton per 24 Hours | 3 Phase, 30 HP, 1440 RPM | – | 8’6″ | 4’1″ | 8’8″ |
| GOYUM MK-IV | 12 – 15 Ton per 24 Hours | 3 Phase, 50 HP, 1440 RPM | 3 Phase, 5 HP, 1440 RPM | 8’8″ | 4’6″ | 9′ |
| GOYUM 150 | 15 – 17 Ton per 24 Hours | 3 Phase, 40 HP, 1440 RPM | 3 Phase, 7.5 HP, 1440 RPM | 8’6″ | 4’7″ | 13′ |
| GOYUM MK-V-C | 18 – 20 Ton per 24 Hours | 3 Phase, 50 HP, 1440 RPM | 3 Phase, 5 HP, 1440 RPM | 11’8″ | 4’3″ | 11’10” |
| GOYUM 240 | 22 – 25 Ton per 24 Hours | 3 Phase, 75 HP, 1440 RPM | 3 Phase, 5 HP, 1440 RPM | 10’2″ | 4’1″ | 7’7″ |
| GOYUM 600 | 30 – 45 Ton per 24 Hours | 3 Phase, 100 HP, 1440 RPM | 3 Phase, 20 HP, 1440 RPM | 14’ | 5’6” | 16’6” |
| GOYUM 1500 | 45 – 125 Ton per 24 Hours | 3 Phase, 150 HP, 1440 RPM | 3 Phase, 25 HP, 1440 RPM | 30’ | 11’6” | 19’6” |
| GOYUM 2400 | 230 – 250 Ton per 24 Hours | 3 Phase, 250 HP, 1440 RPM | 3 Phase, 50 HP, 1440 RPM | 31’ | 7’4” | 23’6” |
Note: The above mentioned Capacity Range includes single pressing as well as pre-pressing. Further capacity differs as per the oil content and density of oilseeds and nuts too.
Are you looking for the most suitable and cost effective Copra Oil Press Machine or Copra Oil Mill Plant to start your own Coconut Oil Manufacturing Business, then you are in the right place. GOYUM is the best and reliable manufacturer, exporter and supplier of oilseed crushing machines.
Please fill the below Enquire Now Form so that we can contact and provide you the best solution for your requirement.
